O-ring muhrli yuqori bosimli FLARE-O armaturalari (SAE 37 ° Flare)
O-ring muhrli yuqori bosimli FLARE-O armaturalari (SAE 37 ° Flare)
O-ring muhrli yuqori bosimli FLARE-O armaturalari (SAE 37 ° Flare)
O-ring muhrli yuqori bosimli FLARE-O armaturalari (SAE 37 ° Flare)
O-ring muhrli yuqori bosimli FLARE-O armaturalari (SAE 37 ° Flare)
O-ring muhrli yuqori bosimli FLARE-O armaturalari (SAE 37 ° Flare)
O-ring muhrli yuqori bosimli FLARE-O armaturalari (SAE 37 ° Flare)
O-ring muhrli yuqori bosimli FLARE-O armaturalari (SAE 37 ° Flare)

O-ring muhrli yuqori bosimli FLARE-O armaturalari (SAE 37 ° Flare)

FLARE-O Fittings are precisely built hydraulic connectors that are intended to provide leak-free performance in applications involving low to medium pressure (up to 3,000 PSI). These fittings guarantee a strong, vibration-resistant connection by integrating an elastomeric O-ring that is positioned strategically within the sealing boundary. They offer better sealing dependability and can be used as a drop-in replacement for conventional flared tube fittings, all while being compatible with SAE 37° flare standards. FLARE-O Fittings, which come in a variety of O-ring materials (Buna-N, Viton, and EPDM), are perfect for demanding hydraulic, mobile, and industrial systems.

MA'LUMOT
Tavsif

1. Leak-Proof Design

The patented O-ring seal eliminates hydraulic fluid leakage, even in high-vibration environments.

Sealing performance surpasses conventional metal-to-metal flare fittings.

2. Pressure & Compatibility

Rated for up to 3,000 PSI, suitable for most low/medium-pressure hydraulic systems.

Conforms to SAE J514 standards (37° flare) and includes SAE-to-NPT adapters for versatility.

3. Materiallar opsiyalari

O-Ring Choices: Buna-N (standard oil-resistant), Viton (high-temperature/fuel-resistant), EPDM (water/chemical-resistant).

Fitting bodies made from durable carbon steel or stainless steel (optional).

4. Oddiy o'rnatish

Direct replacement for SAE 37° flare fittings—no specialized tools required.

Reusable design with minimal maintenance.

undefinedF2403
undefinedF6803 flare-o fittings
undefinedF6803 flare-o high pressure fittings
undefinedF6803 flare-o hydraulic fittings


Asosiy fikrlar:

✔ Pressure Limits: Do not exceed 3,000 PSI. For higher pressures, consult NJ for alternatives.

✔ O-Ring Selection: Match material to fluid type (e.g., Viton for fuel, EPDM for water glycol).

✔ Inspection: Regularly check O-rings for wear and replace if damaged.

Ishlab chiqarish va sifat kafolati

Precision Machining: CNC-tooled fittings ensure exact SAE 37° flare angles for seamless compatibility.

O-Ring Optimization: Finite Element Analysis (FEA) validates seal compression under load.

Testing: 100% pressure-tested to guarantee leak-free performance.

Why Choose NJ FLARE-O Fittings?

✔ Leak-Free Guarantee: O-ring technology outperforms traditional flared fittings.

✔ Wide Compatibility: SAE 37° and NPT adapters simplify system integration.

✔ Durability: Corrosion-resistant coatings and premium materials extend service life.

✔ Cost-Effective: Reduces downtime and fluid loss from leaks.

Texnik ma'lumotlar

FLARE-O UNION STRAIGHT ADAPTER

PART NO.SIZE B1 TUBE O.D. B1 TUBE O.D. B1 SAE 37 B2 SAE 37 B1 DRILL B2 DRILL L LGTH C HEX
F2403-04-04 1/4 1/4 7 / 16-20 7 / 16-20 0.172 0.172 1.37 0.5
F2403-05-05 5/16 5/16 1 / 2-20 1 / 2-20 0.234 0.234 1.37 0.562
F2403-06-04 3/8 1/4 9 / 16-18 7 / 16-20 0.297 0.172 1.4 0.625
F2403-06-05 3/8 5/16 9 / 16-18 1 / 2-20 0.297 0.234 1.4 0.625
F2403-06-06 3/8 3/8 9 / 16-18 9 / 16-18 0.297 0.297 1.41 0.625
F2403-08-06 1/2 3/8 3 / 4-16 9 / 16-18 0.391 0.297 1.52 0.812
F2403-08-08 1/2 1/2 3 / 4-16 3 / 4-16 0.391 0.391 1.62 0.812
F2403-10-06 5/8 3/8 7 / 8-14 9 / 16-18 0.484 0.297 1.68 0.937
F2403-10-08 5/8 1/2 7 / 8-14 3 / 4-16 0.484 0.391 1.78 0.937
F2403-10-10 5/8 5/8 7 / 8-14 7 / 8-14 0.484 0.484 1.88 0.937
F2403-12-08 3/4 1/2 1-1 / 16-12 3 / 4-16 0.609 0.391 1.95 1.125
F2403-12-10 3/4 5/8 1-1 / 16-12 7 / 8-14 0.609 0.484 2.05 1.125
F2403-12-12 3/4 3/4 1-1 / 16-12 1-1 / 16-12 0.609 0.609 2.16 1.125
F2403-14-14 7/8 7/8 1-3 / 16-12 1-3 / 16-12 0.719 0.719 2.21 1.250
F2403-16-08 1 1/2 1-5 / 16-12 3 / 4-16 0.844 0.391 2 1.375
F2403-16-12 1 3/4 1-5 / 16-12 1-1 / 16-12 0.844 0.609 2.2 1.375
F2403-16-16 1 1 1-5 / 16-12 1-5 / 16-12 0.844 0.844 2.25 1.375
F2403-20-16 1-1 / 4 1 1-5 / 8-12 1-5 / 16-12 1.078 0.844 2.38 1.688
F2403-20-20 1-1 / 4 1-1 / 4 1-5 / 8-12 1-5 / 8-12 1.078 1.078 2.43 1.688
F2403-24-16 1-1 / 2 1 1-7 / 8-12 1-5 / 16-12 1.312 0.844 2.58 2
F2403-24-24 1-1 / 2 1-1 / 2 1-7 / 8-12 1-7 / 8-12 1.312 1.312 2.75 2
F2403-32-32 2 2 2-1 / 2-12 2-1 / 2-12 1.781 1.781 3.4 2.625
ariza

Hydraulic Systems: Tractors, construction machinery, and industrial equipment.

Fluid Transfer: Fuel lines, coolant systems, and lubrication networks.

Mobile Equipment: Agricultural, forestry, and mining vehicles.
